Product Details:
|
| Series: | LQ038Q5DR | Keywords Desc.: | SHARP 3.8" TN LCM 320×240 450nits CCFL TTL 40pins |
|---|---|---|---|
| Product Class: | Graphic LCD Display | Product Tags: | Color TFT-LCD,Wide Temperature LCD,Transmissive LCD |
| Application: | Automotive Display | Panel Type: | A-Si TFT-LCD |
| Panel Composition: | LCM | Panel Size: | 3.8" |
| Resolution: | 320×240 | Aspect Ratio: | 15:10 (W:H) |
| Form Factor: | Flat Rectangle Display | Orientation: | Landscape Type |
| Active Area: | 78.72 (W) × 53.64 (H) Mm (A.A) | Outline Dimension: | 117.6 (W) × 69.45 (H) Mm |
| Weight: | 135g (Max.) | LC Family: | TN |
| Polarizer: | Transmissive | Brightness: | 450 (Typ.) |
| Contrast Ratio: | 100:1 (Typ.) | Viewing Angle: | 65/65/40/65 (Typ.)(CR5) (L/R/U/D) |
| Highlight: | sharp lcd screen,sharp lcd flat screen |
||
LQ038Q5DR01 SHARP 3.8 inch TN LCM 320×240 450nits CCFL TTL 40pins
LQ038Q5DR01 General Features
| Panel Brand : | SHARP |
| Panel Model : | LQ038Q5DR01 |
| Panel Type : | a-Si TFT-LCD , LCM |
| Panel Size : | 3.8 inch |
| Resolution : | 320(RGB)×240 , QVGA |
| Display Mode : | TN, Normally White, Transmissive |
| Active Area : | 78.72×53.64 mm |
| Outline : | 117.6×69.45 mm |
| Surface : | Antiglare, Antireflection |
| Brightness : | 450 cd/m2 (Typ.) |
| Contrast Ratio : | 100:1 (Min.) |
| Display Colors : | 262K (6-bit) |
| Response Time : | 30/50 (Typ.)(Tr/Td) |
| Viewing Angle : | 65/65/40/65 (Typ.)(CR≥5) (L/R/U/D) |
| Frequency : | 60Hz |
| Lamp Type : | 1 pcs CCFL |
| Signal Interface : | Parallel RGB (1 ch, 6-bit) , 40 pins |
| Input Voltage : | 3.3V (Typ.)(VCC) |
Our services
1.Your inquiry about our products or the price will be replied within 24 hours!
2.We provide 2 years for warranty and lifelong maintaining ,you will appreciate our warm after-sale service.
3.We will delivery goods as you demand ,you can choose the cheaper and more convenient way!
4.Apart from the Indoor LED Display, Visionled also can offer you LED Pharmacy Cross Display, LED Flexible Display, Outdoor LED Display, LED Gas Price Signs, Indoor/outdoor LED Signs.
N&S Delivery Details:
1) We are shipping this item to worldwide.
2) Our LCD panel orders processed within 1-3 working days of payment verification.
3) If you have not received the item on the Delivery Time. Please contact us. We will track the shipment and get back to your as soon as possible with a reply. Our goal is customer satisfaction.
5) We use the professional & safe package for our LCD screen replacements for you: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
6) We will keep you updated for the Tracking NO. after we ship out the parcel to you.
7) Feel free to contact to us if there is any problems during the shipment process.
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| LQ055T3SX04 | SHARP | 5.5" | 1080×1920 |
| LQ079L1SX06 | SHARP | 7.9" | 1536×2048 |
| LQ079L1SX04 | SHARP | 7.9" | 1536×2048 |
| LQ133M1JW08 | SHARP | 13.3" | 1920×1080 |
| LQ156D1JX02 | SHARP | 15.6" | 3840×2160 |
| LQ156Z1JW01 | SHARP | 15.6" | 3200×1800 |
| LQ133T1JW14B | SHARP | 13.3" | 2560×1440 |
We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
LQ038Q5DR01 Picture
