Product Details:
|
| Panel Size :: | 12.1 Inch | Resolution :: | 800(RGB)×600 , SVGA |
|---|---|---|---|
| Active Area :: | 246×184.5 Mm | Outline :: | 276×209×9.6 Mm |
| Surface :: | Antiglare, Hard Coating (3H) | Brightness :: | 300 Cd/m² (Typ.) |
| Contrast Ratio :: | 800:1 (Typ.) | Display Colors :: | 262K (6-bit) |
| High Light: | industrial touch screen display,industrial lcd panel |
||
12.1 inch M121MNS1 R0 IVO LCM Normally White All Industrial Application
M121MNS1 R0 Specification
| Panel Size : | 12.1 inch |
| Dot Resolution : | 800(RGB)×600 (SVGA) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 82 PPI |
| Aspect Ratio : | 4:3 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.1025×0.3075 mm (H×V) |
| Pixel Pitch : | 0.3075×0.3075 mm (H×V) |
| Weight : | 700g (Max) |
| Surface : | Antiglare, Hard coating (3H) |
| Active Area : | 246×184.5 mm (H×V) |
| Bezel Area : | 249.0×187.5 mm (H×V) |
| Outline Dimension : | 276×209 mm (H×V) |
| Outline Depth : | 9.1±0.5 mm |
| Holes & Brackets : | Face mounting holes (2-Φ3.4, 2-R1.7) on left, right bezel |
| Landscape or Portrait : | Landscape type |
| Touch Panel : | Without |
| Display Mode : | TN, Normally White, Transmissive |
| Brightness : | 300 cd/m² (Typ.) |
| Contrast Ratio : | 800 : 1 (Typ.) (Transmissive) |
| Display Color : | 262K (6-bit) |
| Response Time : | 7/23 (Typ.)(Tr/Td) |
| Viewing Angle : | 80/80/60/80 (Typ.)(CR≥10) (L/R/U/D) |
| White color Chromaticity : | Wx:0.280; Wy:0.301 |
| White Variation : | 1.33 (Max.)(5 points) |
| Sunlight Readable : | N |
| Vertical Frequency : | 60Hz |
| Reverse Scan : | Yes (180°) |
What’s our advantage compared with other suppliers?
(1). Before shipment, we will test every LCD Screen and ensure the quality.
(2). we provide high quality lcd panels for customers all over the world.
(3) .We have DBS, ISO9001 Certifications for our Panels.
(4) .Excellent service on before-sale, on-sale and after-sale.
Packaging & Shipping for Our LCD panel
1. We will ship the LCD display panels within 1-3 workdays after receipt of payment.
2. We can ship to you by UPS/FEDEX/DHL and so some other direct international express line.
Other shipping terms can also be arranged according to specific requirements.
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| P116NWR4 R0 | IVO | 11.6" | 1366×768 |
| C116NWR1 | IVO | 11.6" | 1366×768 |
| C050SWZ9 R1 | IVO | 5.0" | 540×960 |
| C050SWY2-3 | IVO | 4.9" | 480×854 |
| C050SWY2-1 | IVO | 4.9" | 480×854 |
| C045SWY2-0 | IVO | 4.5" | 480×854 |
| C046SWN1-0 | IVO | 4.6" | 480×854 |
| C028SN21-1 | IVO | 2.8" | 240×320 |
