Product Details:
|
| Panel Type: | IGZO TFT-LCD , LCM | Panel Size: | 4.7 Inch |
|---|---|---|---|
| Resolution: | 1080(RGB)×1920 , FHD | Display Mode: | New Mode2, Normally Black, Transmissive |
| Active Area: | 57.996×103.104 Mm | Outline: | 60.4×112.2×1.48 Mm |
| High Light: | sharp lcd display panels,sharp lcd flat screen |
||
Normally Black 4.7 inch LS047T1SC02 Sharp LCD Panel 1080×1920 470 1000:1 16.7M WLED MIPI
LS047T1SC02 Specification
| Panel Size : | 4.7 inch |
| Dot Resolution : | 1080(RGB)×1920 (FHD) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 473 PPI |
| Aspect Ratio : | 9:16 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.0179×0.0537 mm (H×V) |
| Pixel Pitch : | 0.0537×0.0537 mm (H×V) |
| Weight : | 19.0g |
| Active Area : | 57.996×103.104 mm (H×V) |
| Outline Dimension : | 60.4×112.2 mm (H×V) |
| Outline Depth : | 1.38±0.1 mm |
| Landscape or Portrait : | Portrait type |
| Touch Panel : | Without |
| Display Mode : | New Mode2, Normally Black, Transmissive |
| Brightness : | 470 cd/m² (Typ.) |
| Contrast Ratio : | 1000 : 1 (Typ.) (Transmissive) |
| Display Color : | 16.7M (8-bit) |
| Color Gamut : | 71% NTSC (CIE1931) |
| Response Time : | 35 (Max.)(Tr+Td) |
| Viewing Direction : | Symmetry |
| White color Chromaticity : | Wx:0.300; Wy:0.320 |
| White Variation : | 1.33 (Max.)(9 points) |
| Sunlight Readable : | N |
Competitive Advantage:
1. Rich experience.
Having been specialized in this field for years, we have rich experience and widespread sales network around the word.
2. Great quality and high purity
Good quality is one secret for our success.
3. Safest and fastest delivery.
We have mass stock, so that we can arrange the delivery within 24hours once receiving the payment. Tracking number would be informed quickly after shipment.
4. Good after-sales service.
24/7 is available. Try our best to solve various problems customers encountered!
FAQ
Q1: How do we place an order?
A1: Please kindly send us an email specifying the item No., replacements, quantity, other specifications for the Hard disk to place an order.
Q2: How do we make the payment?
A2: We accept T/T, Western Union, MoneyGram, Paypal.
Q3: What's the delivery time?
A3: The delivery time is normally 1-3 working days after payment.
Q4: How would the goods be shipped?
A4: We ship via DHL, UPS, TNT and others.
Here comes our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| LQ156Z1JW01 | SHARP | 15.6" | 3200×1800 |
| LQ133T1JW14B | SHARP | 13.3" | 2560×1440 |
| LQ047K3SX04 | SHARP | 4.7" | 720×1280 |
| LS024Q8UC92 | SHARP | 2.4" | 240×320 |
| LK235D3HA0S | SHARP | 23.6" | 1920×1080 |
| LS055D1SX04 | SHARP | 5.5" | 2160×3840 |
