Product Details:
|
| Contrast Ratio: | 500:1 (Typ.) | Panel Size: | 10.4 Inch |
|---|---|---|---|
| Resolution: | 1024(RGB)×768 , XGA | Display Mode: | FFS, Normally Black, Transmissive |
| Frequency: | 60Hz | Signal Interface: | LVDS (1 Ch, 6-bit) , 14 Pins |
| High Light: | industrial lcd screen,industrial lcd panel |
||
Competitive Advantage:
1. Rich experience.
Having been specialized in this field for years, we have rich experience and widespread sales network around the word.
2. Great quality and high purity
Good quality is one secret for our success.
3. Safest and fastest delivery.
We have mass stock, so that we can arrange the delivery within 24hours once receiving the payment. Tracking number would be informed quickly after shipment.
4. Good after-sales service.
24/7 is available. Try our best to solve various problems customers encountered!
| Panel Size : | 10.4 inch |
| Dot Resolution : | 1024(RGB)×768 (XGA) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 123 PPI |
| Aspect Ratio : | 4:3 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.0685×0.2055 mm (H×V) |
| Pixel Pitch : | 0.2055×0.2055 mm (H×V) |
| Weight : | 235g (Typ.) |
| Surface : | Antiglare (Haze 25%), Hard coating (3H) |
| Active Area : | 210.432×157.824 mm (H×V) |
| Bezel Area : | 216.6×162.4 mm (H×V) |
| Outline Dimension : | 238.6×173.2 mm (H×V) |
| Outline Depth : | 6.8 (Max.) mm |
| Holes & Brackets : | Face mounting holes (4-Ф3.0) + (4-M2) |
| Landscape or Portrait : | Landscape type |
| Touch Panel : | Without |
FAQ
Q1: What's price?
A1: We provide reasonable price and recommend suitable batteries to our customers.
Q2: What's delivery time?
A2: The delivery time is normally 1-3 working days after payment.
Q3: What's the payment?
A3: We accept T/T, Western Union, MoneyGram, Paypal
Q4: Can we visit your factory?
A4: Warmly welcome. Once we have your schedule, we will arrange
professional sales team to follow up your case.
| Display Mode : | FFS, Normally Black, Transmissive |
| Brightness : | 170 cd/m² (Typ.) |
| Contrast Ratio : | 500 : 1 (Typ.) (Transmissive) |
| Display Color : | 262K (6-bit) |
| Color Gamut : | 45% NTSC (CIE1931) |
| Response Time : | 40 (Typ.)(Tr+Td) |
| Viewing Angle : | 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D) |
| Viewing Direction : | Symmetry |
| White color Chromaticity : | Wx:0.318; Wy:0.343 |
| White Variation : | 1.40 (Max.)(5 points) |
| Sunlight Readable : | N |
Here comes our other LCD panels stock for your easy reference:
Pls contact to us for more stock information: salespm@nselectronic.com.hk
| Panel Model | Brand | Size | Resolution |
| HVT20QV1 | HYDIS | 2.0" | 240×320 |
| HVT15QC1-D00 | HYDIS | 1.5" | 240×320 |
| HVA37WV1-DE0 | HYDIS | 3.7" | 480×800 |
| HVA35WV1-D01 | HYDIS | 3.5" | 480×800 |
| HVA35FV1 | HYDIS | 3.5" | 480×854 |
| HVA32WV1-D00 | HYDIS | 3.2" | 480×800 |
| HV121X02-100 | HYDIS | 12.1" | 1024×768 |
| HV050V01-201 | HYDIS | 5.0" | 640×480 |
| HV050V01-200 | HYDIS | 5.0" | 640×480 |
