Product Details:
|
| Panel Brand: | SHARP | Panel Model: | LQ104S1LG2A |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD , LCM | Panel Size: | 10.4 Inch |
| Resolution: | 800(RGB)×600 , SVGA | Display Mode: | TN, Normally White, Transmissive |
| High Light: | sharp lcd display panels,sharp lcd flat screen |
||
LQ104S1LG2A Sharp LCD Panel 10.4 inch with 211.2×158.4 mm Active Area
LQ104S1LG2A Detail
| Panel Brand : | SHARP | |
| Panel Model : | LQ104S1LG2A | |
| Panel Type : | a-Si TFT-LCD , LCM | |
| Panel Size : | 10.4 inch | |
| Resolution : | 800(RGB)×600 , SVGA | |
|
TN, Normally White, Transmissive | |
| Active Area : | 211.2×158.4 mm | |
| Outline : | 246.5×179.4 mm | |
| Surface : | Antiglare, Hard coating (3H) | |
| Brightness : | 350 cd/m² (Typ.) | |
|
500:1 (Typ.) | |
| Display Colors : | 262K (6-bit) | |
| Response Time : | 10/25 (Typ.)(Tr/Td) | |
| Viewing Angle : | 70/70/50/60 (Typ.)(CR≥10) (L/R/U/D) | |
| Lamp Type : | 2 pcs CCFL Without Driver | |
|
LVDS (1 ch, 6-bit) , 20 pins | |
| Input Voltage : | 3.3V (Typ.) |
FAQ
Q1: Can I place sample order first?
A1: Yes, we will quote you different prices for small, medium and large qty. You can order with different price for different qty.
Q2: How could I pay them?
A2: We accept T/T, Western Union, MoneyGram, Paypal.
Q3: How to place the order?
A3: Please send us your purchase order by e-mail, whatsapp or Skype or you can ask us to send you a Proforma Invoice for your order.
Q4: How long can I get my order?
A4: For samples, we will finish production and ship within 1-3 working days. For bulk orders, that will base on the order quantity.
Q5: How to send us the products?
A5: We usually use DHL, UPS, FedEx to ship our LCD screen replacements to our clients.
N&S Delivery Details:
1) We are shipping this item to worldwide.
2) Our LCD panel orders processed within 1-3 working days of payment verification.
3) If you have not received the item on the Delivery Time. Please contact us. We will track the shipment and get back to your as soon as possible with a reply. Our goal is customer satisfaction.
5) We use the professional & safe package for our LCD screen replacements for you: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
6) We will keep you updated for the Tracking NO. after we ship out the parcel to you.
7) Feel free to contact to us if there is any problems during the shipment process.
| Panel Size : | 10.4 inch | |
| Dot Resolution : | 800(RGB)×600 (SVGA) | |
| Pixel Configuration : | RGB Vertical Stripe | |
| Pixel Density : | 96 PPI | |
| Aspect Ratio : | 4:3 (H:V) | |
|
Flat Rectangle Display | |
| Dot Pitch : | 0.088×0.264 mm (H×V) | |
| Pixel Pitch : | 0.264×0.264 mm (H×V) | |
| Weight : | 620g (Max.) | |
| Surface : | Antiglare, Hard coating (3H) | |
|
211.2×158.4 mm (H×V) | |
| Bezel Area : | 214.6×162.4 mm (H×V) | |
| Outline Dimension : | 246.5×179.4 mm (H×V) | |
| Outline Depth : | 15.5 (Max.) mm | |
| Holes & Brackets : | Face mounting holes (2-Φ3.4, 2-3.4×4.4) | |
| Landscape or Portrait : | Landscape type | |
|
Without |
Here comes our other LCD panels stock for your easy reference:
Pls contact to us for more stock information: salespm@nselectronic.com.hk
| Panel Model | Brand | Size | Resolution |
| LQ055T3SX04 | SHARP | 5.5" | 1080×1920 |
| LQ079L1SX06 | SHARP | 7.9" | 1536×2048 |
| LQ079L1SX04 | SHARP | 7.9" | 1536×2048 |
| LQ133M1JW08 | SHARP | 13.3" | 1920×1080 |
| LQ156D1JX02 | SHARP | 15.6" | 3840×2160 |
LQ104S1LG2A Picture
