Product Details:
|
| Panel Brand: | SHARP | Panel Model: | LQ084V3DG03 |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD , LCM | Panel Size: | 8.4 Inch |
| Resolution: | 640(RGB)×480 , VGA | Display Mode: | TN, Normally White, Transmissive |
| High Light: | sharp lcd screen,sharp lcd flat screen |
||
LQ084V3DG03 Antiglare Sharp LCD Panel 8.4 inch with 170.88×128.16 mm
LQ084V3DG03 Detail
| Panel Brand : | SHARP | |
| Panel Model : | LQ084V3DG03 | |
| Panel Type : | a-Si TFT-LCD , LCM | |
| Panel Size : | 8.4 inch | |
| Resolution : | 640(RGB)×480 , VGA | |
|
TN, Normally White, Transmissive | |
| Active Area : | 170.88×128.16 mm | |
| Outline : | 199.5×149.5 mm | |
| Surface : | Antiglare | |
| Brightness : | 400 cd/m² (Typ.) | |
| Contrast Ratio : | 600:1 (Typ.) | |
| Display Colors : | 262K (6-bit) | |
| Response Time : | 5/21 (Typ.)(Tr/Td) | |
| Viewing Angle : | 65/65/55/60 (Typ.)(CR≥10) (L/R/U/D) | |
| Lamp Type : | WLED Without Driver | |
| Signal Interface : | Parallel RGB (1 ch, 6-bit) , 33 pins | |
| Input Voltage : | 3.3V (Typ.)(VCC) |
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| LK315T3HC1K | SHARP | 31.5" | 1366×768 |
| LQ055T3SX04 | SHARP | 5.5" | 1080×1920 |
| LQ079L1SX06 | SHARP | 7.9" | 1536×2048 |
| LQ079L1SX04 | SHARP | 7.9" | 1536×2048 |
| LQ133M1JW08 | SHARP | 13.3" | 1920×1080 |
We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
Quality Control:
Make sure No damage, No Scratches, No dusty, No light leakage.
Make sure all functions are 100% tested ok
| Panel Size : | 8.4 inch | |
| Dot Resolution : | 640(RGB)×480 (VGA) | |
| Pixel Configuration : | RGB Vertical Stripe | |
| Pixel Density : | 95 PPI | |
| Aspect Ratio : | 4:3 (H:V) | |
|
Flat Rectangle Display | |
| Dot Pitch : | 0.089×0.267 mm (H×V) | |
| Pixel Pitch : | 0.267×0.267 mm (H×V) | |
| Surface : | Antiglare | |
| Active Area : | 170.88×128.16 mm (H×V) | |
| Bezel Area : | 175.5×133.0 mm (H×V) | |
| Outline Dimension : | 199.5×149.5 mm (H×V) | |
| Outline Depth : | 11.6 (Typ.) mm | |
| Holes & Brackets : | Face mounting holes (4-Φ3.2) | |
| Landscape or Portrait : | Landscape type | |
| Touch Panel : | Without |
What is Our Advantage?
1. We are the professional supplier of the industrial LCD Screen Replacements, located in the biggest components center of the world.
2. We can provide the one-stop purchase service.
3. Our clients can grow their business by focusing on their sales, ware-housing and distribution while we take care of their China buying.
4. Client relationship and production management are the key factors that ensure successful China buying. Your account will be managed by our professional project managers.
5. Fast delivery.
6. Reasonable price.
LQ084V3DG03 Picture
