Product Details:
|
| Brand: | AUO | Model: | G070VTN03.0 |
|---|---|---|---|
| Diagonal Size: | 7.0 Inch | Interface Type: | LVDS (1 Ch, 6/8-bit) , 20 Pins Connector |
| Luminance: | 300 Cd/m² (Typ.) | Active Area: | 152.4(H)×91.44(V) Mm |
| View Direction: | 6 O'clock | Contrast Ratio: | 500:1 (Typ.) (TM) |
| High Light: | WVGA industrial LCD Panel,G070VTN03.0,G070VTN03.0 LCD Panel |
||
G070VTN03.0 0.1905×0.0635 WVGA industrial LCD Panel
Description Of AUO LCD Panel
AUOptronics Corp. (hereafter called AUO) G070VTN01.0 is a 7.0 inch diagonal a-Si TFT-LCD display screen product, with an incorporated WLED lighting system, without backlight driver, without touch screen. Based on datasheet with version of Ver1.0 which was released out on 12 2 2013, G070VTN01.0 supports display 800×480(RGB) (WVGA) with aspect ratio of 15:9 (W:H), whose pixels are arranged in RGB Horizontal Stripe. As for mechanical detail, it features active area of 152.4(W)×91.44(H) mm, outline size of 170(W)×111(H)×8.3(D) mm, viewing area size of 155.2(W)×92.84(H) mm, with surface treament of Antiglare, Hard coating (3H), net weight of 180g.
| Pixel Features : | Resolution | 800×480(RGB), WVGA | Dot Pitch(mm) | 0.1905×0.0635 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Horizontal Stripe | Pixel Pitch(mm) | 0.1905×0.1905 (H×V) [133PPI] | |
| Mechanical Size : | Active Area(mm) | 152.4(H) × 91.44(V) | Bezel Area(mm) | 155.2(H) × 92.84(V) |
| Outline Dim.(mm) | 170(H) × 111(V) | Depth(mm) | 8.0±0.3 | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | - |
| Aspect Ratio | 15:9 (H:V) | Orientation | Landscape type | |
| Mounting : | Side mounting holes (4-M2) on left, right bezel | |||
| Other Spec : | Weight | 180g | Treatment | Antiglare, Hard coating (3H) |
| Basic Information : | Luminance(cd/m²) | 300 (Typ.) | Contrast Ratio | 500:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 65/65/50/60 (Typ.)(CR≥10)  |
Display Mode | TN, Normally White, Transmissive | |
| Best View on | 6 o'clock | Response(ms) | 12/18 (Typ.)(Tr/Td) | |
| Color Performance : | White Coordinate | X:0.310; Y:0.330 | Display Colors | 262K/16.2M (6-bit / 6-bit + FRC) |
| Color Temperature | 6638K | White Uniformity | 1.30 (Max.)(5 points)  |
|
| 1931 Color Gamlt : | NTSC Ratio | 52% | sRGB | 73% coverage |
| Adobe RGB | 55% coverage | DCI-P3 | 54% coverage | |
| Rec.2020 | 39% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
Here comes our other LCD panels stock for your easy reference:
Pls contact to us for more stock information
| H546DAN01.5 | AUO | 5.5" |
| H546DAN08.0 | AUO | 5.5" |
| B080XAN03.5 | AUO | 7.9" |
| B080XAN03.2 | AUO | 7.9" |
| H499TAN05.0 | AUO | 5.0" |
| H520DAN01.1 | AUO | 5.2" |
| B116XAN05.0 CELL | AUO | 11.6" |
| H495TAN01.0 | AUO | 5.0" |
| H598QAN02.1 | AUO | 6.0" |
| M185XTN01.2 CELL | AUO | 18.5" |
| H598QAN01.0 | AUO | 6.0" |
| T430HVN01.2 CELL | AUO | 43" |
Application Of AUO LCD Panel G070VTN03.0
1. digital watches
2. clinical thermometer
3. electronic weight scale
4. wire tester
Advantage Of AUO LCD Panel
>> Quality ensurance
100% AUO original and brand new!
warranty :12 months !You can enjoy the real panels directly from AUO factory;
>> Packing ensurance
all the products are in original package from original factory directly, and all the packages have labels andserial number!
>> Delivery ensurance
We have international logistic center in HK, so we can arrange fastest and most convenient delivery for you !
The reasons you choose us
1).More competitive price! As a professional LCD Distributor, we have our own souring lines &solutions to support us for the more competitive service, not only the price, but also the stock for the hard-to-find LCD panels.
2).Great quality! All LCD Screen we sent are with good quality guarantee, 100% quality check and full one year warranty!
3).Fast delievery! Delivery time will be faster than others.
4).Great shipping service! We have cooperated with DHL,UPS and EMS for long time, so we could promise save much more money on the shipping cost and better service is offered!
5).Best sale-service! Professional team to service with you before sale, on sale & after service.
