Product Details:
|
| Model: | G270ZAN01.1 | Brand: | AUO |
|---|---|---|---|
| Diagonal Size: | 27.0 Inch | Type: | A-Si TFT-LCD, LCM |
| Luminance: | 800 Cd/m² (Typ.) | Interface Type: | V-by-One 8 Lane , 51 Pins Connector |
| Light Source: | WLED , 50K Hours , With LED Driver | Environment: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Support Color: | 1.07B 94% NTSC | Bezel Area: | 602.0(H)×340.4(V) Mm |
| High Light: | High Brightness AUO LCD Panel,G270ZAN01.1,Antiglare AUO LCD Panel |
||
Quick Details
| Model Number: | G270ZAN01.1 |
| Screen Size | 27.0 inch |
| Payment | T/T, Western Union,PAPLY,BANK TRANSFER |
| Color Depth | 1.07B 94% NTSC |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Good View at | Symmetry |
Here comes our other LCD panels stock for your easy reference:
Pls contact to us for more stock information
| H546DAN01.5 | AUO | 5.5" |
| H546DAN08.0 | AUO | 5.5" |
| B080XAN03.5 | AUO | 7.9" |
| B080XAN03.2 | AUO | 7.9" |
| H499TAN05.0 | AUO | 5.0" |
| H520DAN01.1 | AUO | 5.2" |
| B116XAN05.0 CELL | AUO | 11.6" |
| H495TAN01.0 | AUO | 5.0" |
| H598QAN02.1 | AUO | 6.0" |
| M185XTN01.2 CELL | AUO | 18.5" |
| H598QAN01.0 | AUO | 6.0" |
| T430HVN01.2 CELL | AUO | 43" |
| H495TAN01.2 | AUO | 5.0" |
| T650QVN04.5 CELL | AUO | 65" |
| M320DVN01.0 CELL | AUO | 32.0" |
| M238HVN01.0 CELL | AUO | 23.8" |
| Pixel Features : | Resolution | 3840(RGB)×2160, UHD | Dot Pitch(mm) | 0.05175×0.15525 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.15525×0.15525 (H×V) [163PPI] | |
| Mechanical Size : | Active Area(mm) | 596.16(H) × 335.34(V) | Bezel Area(mm) | 602.0(H) × 340.4(V) |
| Outline Dim.(mm) | 630(H) × 368.2(V) | Depth(mm) | 22.9 (Typ.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | - |
| Aspect Ratio | 16:9 (H:V) | Orientation | Landscape type | |
| Mounting : | Side mounting holes (4-M3) on left, right bezel | |||
| Other Spec : | Weight | 3.40Kgs (Typ.) | Treatment | Antiglare |
| Signal Electrical : | Voltage Supply | 12.0V (Typ.) | Current Supply | 1.08/1.3A (Typ./Max.) | ||
|---|---|---|---|---|---|---|
| Consumption | 12.96/15.6W (Typ./Max.) | |||||
| Signal Type : | V-by-One 8 lane | Signal Voltage | - | |||
| Interface Features : | Position |  |
Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| JAE | FI-RTE51S-HF | 1 pcs | 51 pins | 0.5 mm | ||
Application Of AUO LCD Panel G270ZAN01.1
1. display
2. all-in-one machine
3. medical equipment
4. queuing machine
5. security cameras
6. cash register equipment
7. industrial equipment
8. on-board display
