Product Details:
|
| Panel Brand: | TIANMA | Panel Size: | 3.7 Inch |
|---|---|---|---|
| Panel Model: | TM037WDHT01 | Panel Type: | A-Si TFT-LCD, LCM |
| Touch Screen: | Without | Panel Weight: | 35.0g |
| Highlight: | black and white lcd display,lcd display white screen |
||
TM037WDHT01 Tianma 3.7" LCM 480×640 6 o'clock for Handheld & PDA
TM037WDHT01 information
| Panel Model | TM037WDHT01 |
|---|---|
| Panel Brand | TIANMA |
| Descrition | a-Si TFT-LCD ,3.7 inch, 480×640 |
| Panel Type | a-Si TFT-LCD |
| Display Mode | ECB, Normally White, Transflective |
| Active Area | 56.16×74.88 mm |
| Outline | 65×89×3.2 mm |
| Surface | Hard coating |
| Contrast Ratio | 150:1 (Typ.)(Transmissive) |
| Display Colors | 262K (6-bit) , CIE1931 35% |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 80/40/45/50 (Typ.)(CR≥10) (L/R/U/D) |
| Lamp Type | 6S1P WLED Without Driver |
| Signal Interface | CMOS (1 ch, 6-bit) , 39 pins |
| Input Voltage | 1.8/3.0V (Typ.)(VCCIO/VDD) |
| Panel Model | TM037WDHT01 |
|---|---|
| Panel Brand | TIANMA |
| Descrition | a-Si TFT-LCD ,3.7 inch, 480×640 |
| Panel Type | a-Si TFT-LCD |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
| Remarks | R-EVT |
| Dot Resolution | 480(RGB)×640 (VGA) |
|---|---|
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 217 PPI |
| Aspect Ratio | 3:4 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.039×0.117 mm (H×V) |
| Pixel Pitch | 0.117×0.117 mm (H×V) |
| Weight | TBD |
| Surface | Hard coating |
| Active Area | 56.16×74.88 mm (H×V) |
| Bezel Area | 59.06×77.78 mm (H×V) |
| Outline Dimension | 65×89 mm (H×V) |
| Outline Depth | 3.0±0.2 mm |
| Landscape or Portrait | Portrait type |
| Touch Panel | Without |
Our Advantage
As one of the biggest multiple electronic components & LCD panel distributors in China, we are expert in plenty of branded LCD panels, products include but not limited to:
Packaging & Shipping:
Delivery Information:
Our professional testing team will test the LCD panels pcs by pcs, to make sure the LCD screen sent out are with good quality.
Shipping Method:
By Express: FedEx, DHL, EMS, TNT, UPS,
By Logistics: By air
Shipping Time:
From Monday to Saturday 8:00am-17:30pm
Shipping Address:
If by T/T, shipping address as communicate.
