Product Details:
|
| Panel Type: | A-Si TFT-LCD | Resolution: | 640×480 |
|---|---|---|---|
| Panel Size: | 10.4 Inch | Active Area: | 211.2×158.4 Mm |
| Outline: | 246.5×179.4×12.5 Mm | ||
| High Light: | sharp lcd screen,sharp lcd flat screen |
||
LQ104V1DG62 Basic Information
| Panel Model | LQ104V1DG62 |
| Panel Brand | SHARP |
| Descrition | a-Si TFT-LCD ,10.4 inch, 640×480 |
| Panel Type | a-Si TFT-LCD |
| Operating Temperature | -30 ~ 80 °C |
| Storage Temperature | -30 ~ 80 °C |
| Vibration Resistance | 2.0G (19.6 m/s²) |
| Remarks | Strong LCD2; Mass production from Dec. 2007 |
LQ104V1DG62 Mechanical Features
| Dot Resolution | 640(RGB)×480 (VGA) |
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 76 PPI |
| Aspect Ratio | 4:3 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.110×0.330 mm (H×V) |
| Pixel Pitch | 0.330×0.330 mm (H×V) |
| Weight | 580g (Max.) |
| Surface | Antiglare, Hard coating (3H), Antireflection |
| Active Area | 211.2×158.4 mm (H×V) |
| Bezel Area | 214.6×162.4 mm (H×V) |
| Outline Dimension | 246.5×179.4 mm (H×V) |
| Outline Depth | 12.5 (Max.) mm |
| Holes & Brackets | Face mounting holes (2-Φ3.4, 2-R1.7×4.4) on left, right bezel |
| Landscape or Portrait | Landscape type |
| Touch Panel | Without |
